WCC-0108-T4MF-T
WCC-0108-T4MF-T
Thermagrade M12 4-pin 108" straight - Double-thick FEP · 108" · +200°C
Design family Thermagrade
Dimensions
Dimensions
Pinout
Pinout
Output Circuit
Output Circuit
Technical data
Other
- Product Type
- Cable
- Keyway Coding
- A-coded
- Color Code
- DC
- Coupling Thread Gender1
- Male
- Mating Thread / Type Head 2
- M12
- Coupling Thread Gender2
- Female
- Component Type
- Double-ended cordset
- Wire Gauge
- 20 AWG
- Cable O.D.
- 5 mm
- Voltage Rating
- 300
- Amperage Rating
- 4
- Shielding
- Yes
- IP Rating
- IP67
- Mating Thread / Type Head 1
- M12
- Cable Length in feet
- 9
- Cable Length in inches
- 107.9
- Temperature Rating
- -40...+85°C
- Body Diameter
- 20 mm
- Overall Body Length
- 57 mm
- Tool Included
- N/A
- Upper AWG
- 20
- Lower AWG
- 28
Connection
- Gender
- Male
- Orientation Head 1
- Straight
- Pin Count
- 4
- Orientation Head 2
- Straight
- Matched Connector
- WCA-1204-FXAH
Identification
- Family
- Thermagrade
Cable
- Cable Jacket Material
- Double-thick FEP
- Cable Armor
- None
- Cable Length in meters
- 2.74
Housing
- Shell / Coupling Nut Material
- Metal Alloy
- Body Material
- Nickel Zinc Alloy
- Insulator
- Black Polyamide
- Contacts
- Copper Alloy - Gold Plated
- Seal
- NBR
Certifications
